Schmitt Premium cables are manufactured true to the original in Austria: Absolutely accurate fit and handmade in the highest quality. Fast machine manufacturing processes to save costs are deliberately not used here.
The inner cables are made from special cable steel (and not from the today mostly used brittle stainless steel). Therefore, the Schmitt Premium cables do not break as quickly as those from mass production.
Schmitt cables for classic vehicles are manufactured in the same design as it was standard at the time of production of the vehicles. Thus, for all fans of classic vehicles, a cable true to the original is used here. Since an inner cable manufactured in the old way tends to rust, it is lubricated with an Interflon high-performance fluid grease for life.
OEM number for comparison purposes only: 910.8.08.002.2
Dimensions:
Overall length: 56cm Sheath length (incl. caps): 40.5cm Stranded wire diameter: 3mm Sheath diameter: 6mm
End cap length: 21.5mm End cap diameter: 6-8mm
Rubber cap length: 39mm Rubber cap diameter: 16-18mm outside, 11mm inside
Threaded bolt length (w/ hexagonal adjusting screw): 40mm Thread length: 29mm Nut: M7
Adjustment bush length: 21.5mm Diameter: 9.8mm / 10.5mm / 12mm Slot: 1.9mm
Washer outer diameter: 12mm Nipple attachment diameter: 8mm, Width: 12mm Bushing diameter: 6mm, Length: 10.7mm
The inner cables are made from special cable steel (and not from the today mostly used brittle stainless steel). Therefore, the Schmitt Premium cables do not break as quickly as those from mass production.
Schmitt cables for classic vehicles are manufactured in the same design as it was standard at the time of production of the vehicles. Thus, for all fans of classic vehicles, a cable true to the original is used here. Since an inner cable manufactured in the old way tends to rust, it is lubricated with an Interflon high-performance fluid grease for life.
OEM number for comparison purposes only: 910.8.08.002.2
